Elephant foot ferrules are specialized components used in precast concrete construction to create secure and stable anchoring points. Named for their distinctive shape, which resembles an elephant's foot, these ferrules are designed to be embedded into concrete during the casting process.
Made from robust materials like high-strength steel, elephant foot ferrules feature a wide, flared base that provides excellent load distribution and stability. This design ensures that the ferrules remain firmly anchored, even under heavy loads. The top portion of the ferrule usually has a threaded hole or opening for easy attachment of other components or lifting equipment.
Using elephant foot ferrules enhances the safety and efficiency of handling and assembling precast concrete elements. Their reliable performance and stable anchoring make them an essential choice for various construction applications, ensuring strong connections and improved structural integrity.
Customized Materials:
Q235,45#,SS316,SS304
Customized Surface Treatment:Zinc Plating,H.D.G.
Elephant Foot Ferrule Products Specification
| Item Code | Size | SWL (KN) | D | a | b | e | h | Weight (kg/piece) |
|---|---|---|---|---|---|---|---|---|
| PF0110050 | M10 | 8 | 16 | R8 | 35 | 25 | 50 | 0.6 |
| PF0112050 | M12 | 9 | 20 | R10 | 35 | 25 | 50 | 0.6 |
| PF0112070 | M12 | 9 | 20 | R10 | 50 | 30 | 70 | 0.6 |
| PF0112096 | M12 | 9 | 20 | R10 | 50 | 30 | 96 | 0.6 |
| PF0116070 | M16 | 17 | 25 | R10 | 50 | 35 | 70 | 0.6 |
| PF0116095 | M16 | 19 | 28 | N12 | 50 | 35 | 95 | 0.6 |
| PF0116096 | M16 | 17 | 25 | R10 | 50 | 40 | 96 | 0.6 |
| PF0120070 | M20 | 25 | 30 | N12 | 50 | 30 | 70 | 0.6 |
| PF0120095 | M20 | 25 | 30 | N12 | 50 | 50 | 95 | 0.6 |
| PF0120096 | M20 | 23 | 28 | N12 | 50 | 50 | 96 | 0.6 |
| PF0124095 | M24 | 30 | 36 | N12 | 50 | 45 | 95 | 0.6 |
| PF0124096 | M24 | 35 | 40 | N16 | 50 | 45 | 96 | 0.6 |
