A double spherical head anchor is a specialized component in the precast concrete industry, designed to provide a secure and versatile lifting point for concrete elements. This anchor features two spherical heads, allowing for dual lifting points, which enhances the stability and balance during the lifting process.
Manufactured from high-strength steel, double spherical head anchors are embedded into the concrete during the casting process. The dual spherical heads ensure even load distribution and provide multiple attachment points for lifting equipment. This design improves the safety and efficiency of handling and transporting precast concrete components, reducing the risk of accidents and structural damage.
The double spherical head anchor is particularly useful for larger and more complex concrete elements that require additional support. By using these anchors, construction projects benefit from improved handling precision, increased safety, and greater operational efficiency, making them an essential tool in modern precast concrete construction.
Customized Materials:
Q345D,20Mn2,CM690,SS316,SS304
Customized Surface Treatment:Plain (Original),Zinc Plating,H.D.G.
Products Specification
| Item Code | Size | SWL (KN) | D | d | b | h | Weight (kg) |
|---|---|---|---|---|---|---|---|
| SH03013055 | 1.3T | 13 | 18 | 10 | 25 | 55 | 0.171 |
| SH03013065 | 1.3T | 13 | 18 | 10 | 25 | 65 | 0.175 |
| SH03013085 | 1.3T | 13 | 18 | 10 | 25 | 85 | 0.180 |
| SH03013120 | 1.3T | 13 | 18 | 10 | 25 | 120 | 0.205 |
| SH03013240 | 1.3T | 13 | 18 | 10 | 25 | 240 | 0.275 |
| SH03025070 | 2.5T | 25 | 25 | 14 | 35 | 70 | 0.255 |
| SH03025085 | 2.5T | 25 | 25 | 14 | 35 | 85 | 0.275 |
| SH03025120 | 2.5T | 25 | 25 | 14 | 35 | 120 | 0.325 |
| SH03025170 | 2.5T | 25 | 25 | 14 | 35 | 170 | 0.375 |
| SH03025240 | 2.5T | 25 | 25 | 14 | 35 | 240 | 0.535 |
| SH03050120 | 5.0T | 50 | 36 | 20 | 50 | 120 | 0.565 |
| SH03050240 | 5.0T | 50 | 36 | 20 | 50 | 240 | 0.915 |
Contact Us to get product catalogue
